High Efficiency Boiler Economizer with Max. 20t/h Steam Production for Power Station Natural Circulation Systems
| Lugar de origem | Jiangsu, China |
|---|---|
| Marca | HDB |
| Quantidade de ordem mínima | 1 tonelada |
| Preço | $22,000-25,000 / ton |
Contacte-me para amostras e cupons grátis.
whatsapp:0086 18588475571
WeChat: 0086 18588475571
skype: sales10@aixton.com
Se tiver alguma preocupação, fornecemos ajuda online 24 horas por dia.
xDetalhes do produto
| Tipo | Circulação natural | Uso | Estação de energia |
|---|---|---|---|
| Estrutura | tubo de água | Pressão | Alta pressão |
| Produção de vapor | Max. 20 t/h | Estilo | horizontal |
| Combustível | Aquecidos a carvão | Saída | Água quente |
| Combustível do projeto | Combustível de carvão | Material | Placas de aço de caldeiras especiais |
| Tipo de combustível | Coca -cola Gás | Peso | 1-20 toneladas |
| Processo de fusão | EF+LF + VD | Padrão de UT | ASTM A388 ou EN10228 |
| Padrão de material | ASTM, EN ou ISO | ||
| Destacar | Max. 20t/h Boiler Economizer,Natural Circulation Boiler Economizer,Power Station Heat Exchanger |
||
Descrição de produto
Hua Dong Heating System Quality Safety Boiler Economizer
Boiler economizers are heat exchange devices with finned tubes that heat liquids (typically water) up to but not exceeding the boiling point. We manufacture three types of boiler economizers:
- Bare tube economizer
- H-finned tube economizer
- Spiral finned tube economizer
The H-finned tube economizer is a highly efficient heat exchanger consisting of H-finned tubes. Compared to bare tube economizers, H-finned tube models offer:
- Increased heat exchange area
- Reduced number of tubes required
- Expanded flue gas flow area to decrease flow speed and abrasion
Our H-finned tubes can be manufactured as double H-finned tubes with high rigidity for long tube row applications. The spiral finned economizer features a new design with spiral fin tubes to overcome abrasion issues and extend service life.
Specifications
| Description | Boiler economizer |
| Material | Alloy steel, Carbon steel, SA210C, SA213T22, etc. |
| Material standard | ASTM, EN or ISO etc. |
| Dimension | Customized |
| Weight | 10 ton - 1000 ton |
| Smelting Process | EF+LF+VD |
| Process | Material→Ingot→Hot/Cold-Rolling→Heat treatment (Normalizing+ tempering)→Inspection→rough machining→UT→2nd Heat treatment→finishing machining→Inspection |
| UT standard | ASTM A388 or EN10228, etc. |
Quality Control
- Impact test and Strength calculation report with applied materials information
- 100% NDT (non-destructive inspection) report of steel plate, tube and electrode
- X-ray, γ-ray and liquid penetrant test inspection report (welding seam) to ensure boiler quality
- Hydraulic test report to verify standard working pressure and safety
